Applications

Suitable for powdered and granular materials;

Suitable for the continuous, metered feeding of materials;

Suitable for feeding materials in gravity or pneumatic conveying systems.

Features

Suitable for both powdered and granular materials;

Capable of uniform, continuous operation with both soft and hard materials;

Effectively reduces wear on the housing and impeller;

Reinforced bearing support design, enhancing the fit precision between the rotor and valve body;

Axial seals utilise an air seal & double-lip oil seal design to minimise leakage;

Low clearance between the rotor and housing improves feeding and discharging efficiency.

Technical Specifications

Pressure Range: <1.5 bar

Temperature Range: -20 to 250°C

Flange Standard: ANSI 150#, HG, SH, GB or client’s standard

Suitable Medium: Granular and powdered materials

Outboard Bearings: Separated from the product by a purged seal

Hazardous Environments (optional) ATEX: Suitable for use in hazardous environments

Accessories (optional): Exhaust hopper, material shoe, speed switch, bracket, compensator, etc.

* Customisation available
